10/5-60/40 Plano Convex Lens
Product Specification
Place of Origin:
China
Brand Name:
Advance
Certification:
ROHS\Reach
Model Number:
as requirements
Minimum Order Quantity:
1
Price:
$0.2~$100
Payment Terms:
T/T&L/C
Supply Ability:
1000k/per month
Product Details
Highlight:
60/40 Plano Convex Lens
,10/5 plano convex lens
,BK7 telescope lens
Product Name:
10/5-60/40 Plano Convex Lens
Type:
Spot Light Lens
Surface Quality:
10/5-60/40
Focal Length:
Custom Request
Description:
BK7 Optical Glass
Coating:
AR-coated
Interface Type:
Canon EF-S
Diameter:
25 Mm
Centerthickness:
5 Mm
Width Tolerance:
+/-0.01mm
Style:
Antique
Application Area:
Lighting,Laser Etc
Shape:
Spherical
Focal Length Tolerance:
+/-1%
Material:
Optical Glass
Operatingtemperature:
-20 To 70 °C
Filter Ring Color:
Black,Sliver,Gold
Customized Support:
OEM, ODM
Coating Choice:
Green
Refractiveindex:
1.52
Product Description
10/5-60/40 Plano Convex Lens
In the sophisticated landscape of industrial optics, the 10/5-60/40 Plano Convex Lens serves as a fundamental building block for systems requiring light collimation, beam focusing, and high-fidelity imaging. A Plano Convex Lens is strategically designed with one flat (plano) surface and one spherical (convex) surface, resulting in a positive focal length. This specific 10/5-60/40 Plano Convex Lens configuration is highly valued for its ability to minimize spherical aberration in applications where the conjugate ratio is greater than 5:1, such as focusing parallel light rays onto a single point.
The manufacturing of the 10/5-60/40 Plano Convex Lens focuses on surface integrity and material homogeneity. By offering a range of surface qualities—from the commercial-grade 60/40 scratch-dig to the ultra-precision laser-grade 10/5—we ensure that every 10/5-60/40 Plano Convex Lens is perfectly matched to its intended environment. Whether you are integrating a 10/5 Plano Convex Lens into a high-energy laser system or utilizing a 60/40 Plano Convex Lens for general illumination, our production process prioritizes optical clarity and dimensional stability. By selecting a 10/5-60/40 Plano Convex Lens, optical engineers gain access to a versatile component that combines high transmission with predictable performance across the visible and infrared spectrum.
Technical Specifications
To provide full transparency regarding our fabrication capabilities, the following table details the technical standards applied to the 10/5-60/40 Plano Convex Lens series. These parameters ensure that every Plano Convex Lens meets the rigorous demands of professional optical assemblies.
| Feature | Specifications for 10/5-60/40 Plano Convex Lens | Strategic Advantage |
|---|---|---|
| Surface Quality | 10/5 to 60/40 Scratch-Dig | Tailored scatter control for the 10/5-60/40 Plano Convex Lens |
| Material Substrates | BK7, Fused Silica, ZnSe, Sapphire | Spectral flexibility for each Plano Convex Lens |
| Diameter Tolerance | ±0.005 mm to ±0.05 mm | Precision mechanical fit for the 10/5-60/40 Plano Convex Lens |
| Center Thickness Tol. | ±0.01 mm | Pathlength consistency in a 10/5-60/40 Plano Convex Lens |
| Focal Length Tol. | ±1% | Repeatable beam control in every Plano Convex Lens |
| Surface Accuracy (N) | 1~3 λ (Standard) | High-fidelity wavefront for the 10/5-60/40 Plano Convex Lens |
| Irregularity (ΔN) | 0.1~0.5 λ | Essential for HD imaging through a Plano Convex Lens |
| Centration / Decenter | 3″ to 1′ | Prevents axial shift in the 10/5-60/40 Plano Convex Lens |
Applications & Benefits
The 10/5-60/40 Plano Convex Lens is a cornerstone of precision photonics. Below, we outline the functional benefits and diverse implementations of the Plano Convex Lens in global industries:
- Customizable Surface Integrity: By providing the 10/5-60/40 Plano Convex Lens in multiple surface grades, we allow users to balance cost and performance. The 10/5 Plano Convex Lens is ideal for preventing laser damage, while the 60/40 Plano Convex Lens offers an economical solution for sensors.
- Minimal Spherical Aberration: When oriented with the curved surface facing the source, the 10/5-60/40 Plano Convex Lens provides superior focusing compared to other singlet designs.
- Broad Material Compatibility: Our 10/5-60/40 Plano Convex Lens can be fabricated from UV-grade Fused Silica for lithography or high-index glass for compact imaging.
- Widespread Industrial Use:
- Laser Materials Processing: Using the 10/5-60/40 Plano Convex Lens to focus high-power fiber lasers for metal cutting.
- Biomedical Imaging: Integrating a precision Plano Convex Lens into confocal microscopes for cellular analysis.
- Industrial Sensing: Utilizing the 60/40 Plano Convex Lens in high-speed sorting and alignment systems.
- Defense & Aerospace: Implementing a ruggedized 10/5-60/40 Plano Convex Lens in target designation and ranging hardware.
Product Images
Frequently Asked Questions
Q1: Why is the "10/5" rating critical for a 10/5-60/40 Plano Convex Lens in laser systems?
Answer: In high-energy applications, micro-scratches on a Plano Convex Lens can absorb energy and cause thermal failure. A 10/5 Plano Convex Lens ensures virtually zero surface defects, maximizing the Laser Induced Damage Threshold (LIDT) for the 10/5-60/40 Plano Convex Lens.
Q2: How should I orient the 10/5-60/40 Plano Convex Lens for optimal focusing?
Answer: To minimize aberration, the 10/5-60/40 Plano Convex Lens should be oriented with the curved surface facing the collimated incident light. This ensures the light is refracted across both surfaces of the Plano Convex Lens more evenly.
Q3: Can the 10/5-60/40 Plano Convex Lens be provided with custom AR coatings?
Answer: Absolutely. We offer specialized Anti-Reflection (AR) coatings for the 10/5-60/40 Plano Convex Lens across UV, Visible, and IR bands, increasing the transmission of the Plano Convex Lens to over 99.5%.
Q4: What is the benefit of the ±0.005 mm tolerance for the 10/5-60/40 Plano Convex Lens?
Answer: In high-end optomechanical assemblies, any play in the lens mount can cause decentration. Our precision ±0.005 mm diameter tolerance for the 10/5-60/40 Plano Convex Lens ensures a perfect fit, maintaining the optical axis integrity of the Plano Convex Lens.
Q5: Is the 10/5-60/40 Plano Convex Lens available in infrared materials like ZnSe?
Answer: Yes. We apply the same 10/5-60/40 standards to IR substrates, making the Plano Convex Lens suitable for thermal imaging and CO₂ laser systems.
Shanghai Advance Optical-Electronics Technology Co.Ltd is a manufacturing enterprise of science and technology. She was founded in 2009, and located at QingPu Industry Park. It only need about half a hour drive from HongQiao International Airport. She gathered many of excellent technicists from the optical intra-industry. And own optical design, optical manufacturing and sales service etc overall ability, wholeheartedly to provide the high quality productions and best service to everyone client.
Business Scope: Specialize in Spherical lens, Aspherical lens, Cylindar lens, Rod lens, Windows glass, optical Filter, optical prism, Reflection lens, OEM aspherical led optical glass plano-convex concave 150 watt led lens camera lenses ect, and provied optical design and assembly service to client, the main market including of Optical-telecomunication, Survey instrument, Laser application, Medical endoscope, Machine vision etc.
Advantage: Beyond ten years experience and had ten thousand kinds optical toolings in stock, that will save much time and cost for the new and old projects.
Operation principle: Integrity, Concrete, Innovation, Win-Win
