Product Details:
|
| Warranty: | - | Customized Support: | OEM, ODM |
|---|---|---|---|
| Material: | BK7 And Other Optical Glass, BK7 And Other Optical Glass,quartz,sapphire,Ge,Si,ZnSe,CaF2 Etc | Surface Quality: | 60/40 |
| Dimension Tolerance: | +/-0.01mm | Angle Tolerance: | 3"~2' |
| Flatness: | N=1~3 | Length: | 5-100mm |
| Width: | 5-100mm | Height: | 5-100mm |
| Length Tolerance: | +/-0.03mm | Width Tolerance: | +/-0.03mm |
| Angle Error: | 2"-3" | Surface Quality: | 10/5~60/40 |
| Application Area: | Imaging,Lighting,Laser Etc | Coating: | Upon Request |
| Port: | Shanghai | ||
| Highlight: | BK7 Optical Glass Prism,Rectangular Optical Glass Prism,Right Angle k9 optical glass |
||
1. Feature of right-angle prism:
2. Specification of right-angle prism:
Our company can customize all-metal mirrors in different diameter specifications according to customers’ different requirements and also provides special all-mental mirrors such as punching, trimming, etc.
| Materials | BK7 or other optical glass,quartz,sapphire,Ge,Si,ZnSe,CaF2 etc |
| Length | 5~100mm |
| Width | 5~100mm |
| Height | 5~100mm |
| Length tolerance | +/-0.03mm |
| Width tolerance | +/-0.03mm |
| Height tolerance | +/-0.03mm |
| Angle tolerance | 2'~3" |
| Irregularity | ΔN=0.1~0.5 |
| Surface accuracy | N=1~3 |
| Surface quality | 10/5~60/40 |
| Coating | Upon request |
| Application area | Imaging,Lighting,Laser etc |
Shanghai Advance Optical-Electronics Technology Co., Ltd. is a technology-based production enterprise,officially established in September 2009,the plant site located in Qingpu Industrial Park, Shanghai, only half an hour's drive from Shanghai Hongqiao International Airport. The company gathers several excellent technicans in optical industry, has comprehensive supporting capabilities such as optical mechanical and electrical design, processing and sales services, and wholeheartedly provides each customer with high-quality and convenient products and services. Business scope: optical mechanical and electrical module development, precision optical element processing, camera lens design and processing, optical design and optical path optimization solution, technical consultation and after-sales service. Application fields: machine vision, artificial intelligence, biomedical, smart city, high-end monitoring, testing instruments, military equipment, laser etching, special lighting, scientific research institutions, etc.
