Spherical Concave 1.5mm To 300mm Reflector Mirrors

I'm Online Chat Now

Spherical Concave 1.5mm To 300mm Reflector Mirrors

Spherical Concave 1.5mm To 300mm Reflector Mirrors
Spherical Concave 1.5mm To 300mm Reflector Mirrors Spherical Concave 1.5mm To 300mm Reflector Mirrors Spherical Concave 1.5mm To 300mm Reflector Mirrors Spherical Concave 1.5mm To 300mm Reflector Mirrors Spherical Concave 1.5mm To 300mm Reflector Mirrors Spherical Concave 1.5mm To 300mm Reflector Mirrors

Large Image :  Spherical Concave 1.5mm To 300mm Reflector Mirrors

Product Details:
Place of Origin: Shanghai, China
Brand Name: Advance
Model Number: -
Payment & Shipping Terms:
Minimum Order Quantity: 10 Pieces
Price: $100.00/Pieces 10-99 Pieces
Packaging Details: Vacuum+EVA+Carton
Supply Ability: 10000000 Piece/Pieces per Month

Spherical Concave 1.5mm To 300mm Reflector Mirrors

Description
Warranty: -, 16 Month Customized Support: OEM, ODM
Usage: Optical, Optical System Structure: Custom
Shape: Custom Product Name: Lighting Accessories Standard Reflector Bowens Mount
Model: I50 Application: Optical Shops
Certificate: CE ISO Type: Ophthalmic Optical Equipments
Weight: Light Material: Aluminum Alloy
Port: Shanghai
High Light:

300mm Reflector Mirrors

,

1.5mm Reflector Mirrors

,

Concave spherical mirrors

OEM BK7 Aluminum Reflector Concave Mirrors Glass Lens Optical Spherical Telescope Reflector Mirrors



Application:

1) Special full reflection type of laser lamp: 0 ~ 57 degrees , 650 nm, 532 n, 475nm reflection more than 99.8%.



2) Special purpose for projector and optical instrument: visible total reflection 400~680nm reflection is more than 99.9%



3) Total reflection of ordinary optical instrument is 0 ~ 57 degree, 420m~680nm reflection is more than 95%.



Specification



Materials BK7 or others optical glass. quartz. sapphire . Ge. Si- ZnSe· CaF2 etc.
Diameter 1.5~300mm
Radius R 0.8mm-∞
Focal length -30000mm~+ 30000mm
Center thickness tolerance +/-0.01mm
Diameter tolerance +/-0.005mm
Focal length tolerance +/-1%
Surface accuracy N=1~3
Irregularity ΔN=0.1~0.5
Decenter 3"~1'
Surface quality 10/5~60/40
Coating Upon request
Application area Imaging. Lighting Laser etc


Spherical Concave 1.5mm To 300mm Reflector Mirrors 0

Spherical Concave 1.5mm To 300mm Reflector Mirrors 1

Spherical Concave 1.5mm To 300mm Reflector Mirrors 2
Spherical Concave 1.5mm To 300mm Reflector Mirrors 3
Spherical Concave 1.5mm To 300mm Reflector Mirrors 4
Spherical Concave 1.5mm To 300mm Reflector Mirrors 5
1.5mm To 300mm Optical Lens Design , BK7 Dichroic Optical Filter 4

Recommend Products
1.5mm To 300mm Optical Lens Design , BK7 Dichroic Optical Filter 5
Company Profile
1.5mm To 300mm Optical Lens Design , BK7 Dichroic Optical Filter 6


Shanghai Advance Optical-Electronics Technology Co., Ltd. is a technology-based production enterprise,officially established in September 2009,the plant site located in Qingpu Industrial Park, Shanghai, only half an hour's drive from Shanghai Hongqiao International Airport. The company gathers several excellent technicans in optical industry, has comprehensive supporting capabilities such as optical mechanical and electrical design, processing and sales services, and wholeheartedly provides each customer with high-quality and convenient products and services. Business scope: optical mechanical and electrical module development, precision optical element processing, camera lens design and processing, optical design and optical path optimization solution, technical consultation and after-sales service. Application fields: machine vision, artificial intelligence, biomedical, smart city, high-end monitoring, testing instruments, military equipment, laser etching, special lighting, scientific research institutions, etc.



Company Advantages:

1. Have comprehensive design, production and sales capabilities, and provide customers with one-stop convenient procurement services; 2. It has tens of thousands of optical molds and samples, which can provide customers with fast proofing services with low cost; 3. Be able to participate in the customer's new product research and development early, provide feasible plans and suggestions, and make the project less detours;
Certifications
1.5mm To 300mm Optical Lens Design , BK7 Dichroic Optical Filter 7
Exhibition
1.5mm To 300mm Optical Lens Design , BK7 Dichroic Optical Filter 8
Packing & Delivery
1.5mm To 300mm Optical Lens Design , BK7 Dichroic Optical Filter 9
1.5mm To 300mm Optical Lens Design , BK7 Dichroic Optical Filter 10

FAQ
Q: What are your main products or Which fiefd do your products be used?
A: We are specialized in optical design.optical element processing,Lenses assembly,Such as Spherical lens,Aspherical
lens,Cylindarlens,Reflector mirror,Filter,Rod lens,Camera lenses etc,and our products are wide used to these filed such as
imaging,Laser,Lighting etc.

Q: What's your advantage?
1. We have about ten thousands optical modules and fixturesin stock,and employ several outstanding technicians and manager.that
will enable to provide customer excellent quality in shortleadtime,also can save the plenty of develop cost for customer.
2. We can help customer to optimize the optical system whichthey dislike,and provide the free optical solution or suggestion.
Q: What's your MOQ?
A: 10pcs.
Q: What's your leadtime?
A: 1day for inventory and 25~35days for the new project.

Q: What's your shipping type?
A: Usually by Fedex,DHL,TNT,EMS etc or Customer appointed.

Q: What's the payment condition?
A: T/T,L/C,VISA,Paypal,Alipay or Negotiation.

Q: What's your quality guarantee period?
A: Three years.
