Product Details:
|
| Warranty: | 3 Years | Coating: | No Coat |
|---|---|---|---|
| Usage: | Optical | Structure: | Plano Convex |
| Diameter: | 15mm | Material: | K9 |
| Focal Length: | 150mm | Name: | Cylinder Lens |
| Surface Accuracy: | N=1~0.5 | Centerthickness Tolerance: | +/-0.001mm |
| Focal Length Tolerance: | +/-1% | Surface Quality: | 60/40 |
| Application Area: | Laser | Port: | Shanghai |
| Interface Type: | Canon EF-S | Diameter: | 25 Mm |
| Centerthickness: | 5 Mm | Width Tolerance: | +/-0.01mm |
| Style: | Antique | Application Area: | Lighting,Laser Etc |
| Shape: | Spherical | Material: | Optical Glass |
| Operatingtemperature: | -20 To 70 °C | Filter Ring Color: | Black,Sliver,Gold |
| Customized Support: | OEM, ODM | Coating Choice: | Green |
| Refractiveindex: | 1.52 | ||
| Highlight: | plano convex Optical Glass Lens,NIR coated Optical Glass Lens,PCX Cylinder Lenses |
||
Shanghai Advance Optical Electronics Technology Co.,Ltd., a professional OEM and ODM optical factory in China.
|
Materials
|
k9
|
|
Diameter
|
15mm
|
|
Radius
|
R0.8mm-∞
|
|
Focal length
|
-30000mm~+30000mm
|
|
Center thickness tolerance
|
+/-0.01mm
|
|
Diameter tolerance
|
+/-0.005mm
|
|
Focal length tolerance
|
+/-1%
|
|
Surface accuracy
|
N=1~3
|
|
Irregularity
|
ΔN=0.1~0.5
|
|
Decenter
|
3''~1''
|
|
Surface quality
|
10/5~60/40
|
|
Coating
|
Upon request
|
|
Application area
|
Imaging,Lighting,Laser etc
|
